* technical parameters:

1. Quality requirements: according to the professional domestic sales of power tools and "GS,CE,EMC"

2. Rated voltage/frequency: 230V/50Hz

3. No-load speed: 0-2800r/min

4. Input power: 850W

5. Continuous load working time should be over 300 hours

* electronic structure table:

1. Insert head: European double circular insert, 16A, 250V ~ yk-002

2. On/off: TNING

3. Electricity capacity, VDE

4. Power cord: h05rn-f,2* 0.75mm2, exposed length 2m

5. Electric machine: baosteel 800, enamelled wire resistant to high temperature

The above components shall be equipped according to GS certification.

* materials and colors of each part:

1. Front of chassis: red, 1797C

2. Motor housing: red, 1797C

3. Auxiliary handle: black, soft leather black

4. Switches and buttons: plastic, black

5. Function conversion knob: plastic, black

6. Gear material 42CrMo, impact gear material 20CrMnTi,

7. High quality cold-rolled silicon steel sheet, high temperature enameled wire,

* mechanical drill chuck, diameter 13MM, peacock brand

* random accessories:

1. 1 drill chuck key

2. One auxiliary handle

3. 1 metal depth ruler

4. One carbon brush
